IEEE 802.1 Time-Sensitive Networking (TSN) is an enabler of Industry 4.0, i.e., smart factory of cyber physical systems. TSN is the foundation to provide connectivity and real-time quality of service to time and mission critical industrial applications on converged networks of operations technology and information technology and converging multiple independent applications in one network enabling real-time communication on the same infrastructure (cables, bridges). TSN meets these requirements by providing interoperability via open standards. TSN provides synchronization and supports real-time communication for, e.g., closed loop control over a single standard Ethernet network.
This webinar series would be of interest to those in the following industries:
IEEE P802.1DG: Evolving the In-Vehicle Network from Audio/Video Bridging (AVB) to TSN
RECORDED THURSDAY, 26 OCTOBER 2023
Often the term TSN (Time-Sensitive Networking) is associated only with Time Aware Shaper operation (scheduled traffic). This is however not true, especially in the automotive context, as TSN also entails other traffic-shaping mechanisms previously introduced as Audio/Video Bridging (AVB) as well as further 802.1 functionality.
The predominant task of creating a Profile is to reduce this broad range of possible features to those which best fit the in-vehicle use-case.
This webinar will discuss the IEEE P802.1DG TSN Profile for Automotive In-Vehicle Ethernet Communications, which has been updated significantly in its current draft version.
Automotive Network Architect, Ethernovia BV
Max Turner joined BMW at the end of 2002, where he worked on MOST and FlexRay physical layer specifications. From 2005 to 2008 Max was working at the BMW Technology Office in Palo Alto, California where he focussed on DSRC based V2x communication around IEEE802.11P and IEEE1609. After his return to Munich he started the introduction of Ethernet into AUTOSAR and became part of the group developing the Diagnostics over IP (ISO13400) specification. Max was part of the team introducing Ethernet (SOME/IP and AVB) into BMW vehicles and was active in IEEE and AVnu to foster automotive Ethernet adaptations. Max spent two years at Jaguar Land Rover in Gaydon UK, where he worked on vehicle network architectures focussed on automated driving, before joining Ethernovia in Dec. 2019. He currently serves as the Automotive Network Architect and since 2021 he is the Editor of IEEE 802.1DG.
REGISTER FOR THE WEBINAR SERIES TO ACCESS
IEC/IEEE 60802TM: The Case for the Converged Network in the Factory of the Future
This webinar will discuss the IEC/IEEE 60802 TSN profile for industrial automation. It will also discuss features like time-synchronization and scheduled traffic to address some aspects of the industrial use case. Further, a common layer 2 provides the opportunity for a common approach to resource management which in turn offers the opportunity for improved offline engineering and an automated approach to on-boarding new devices in a network (Plug and Produce).
TSN to the Fore of the Transition to 5G with IEEE 802.1CM™
This webinar will discuss the motivation and methodology behind the development of IEEE 802.1CM™-2018 Time-Sensitive Networking (TSN) for Fronthaul, what the standard provides in terms of principles, structure, deployment, configuration, and how it combines relevant parts of the TSN toolset to ITU-T synchronization solutions to enable a bridged IEEE 802.3™ Ethernet network to transport time-sensitive fronthaul traffic flows using CPRI or packetized eCPRI. This webinar will also address why the IEEE 802.1CMde™-2020 amendment matters and what it brings that reinforces the position of TSN, via IEEE 802.1CM, at the fore of the ongoing transition from 4G to 5G.
IEEE 802.1 TSN Webinar: Audio/Video Bridging
This webinar describes the goals of the AVB project and the IEEE 802.1 Standards that were developed for each problem area and their solutions. This gives participants a better understanding of what the AVB project did and why, as a method to better understand the structure of the TSN Standards and the subsequent TSN use case Profiles.
The Audio Video Bridging (AVB) IEEE 802.1 Standards work culminated with the AVB Profile Standard (IEEE 802.1BA). This initial Time Sensitive Networking (TSN) project provides a plug-and-play solution for audio and video streams by reserving bandwidth for these streams ahead of non-reserved flows.
The Transport and Impact of Synchronization in Time-Sensitive Networking - An Introduction to IEEE 802.1AS
This webinar will give an introduction to IEEE 802.1AS, including synchronization concepts and applications. IEEE 802.1AS is a profile of IEEE Std 1588. It specifies protocols and procedures that enable systems and networks to meet time-synchronization requirements for time-sensitive applications, such as audio, video, and time-sensitive control. Synchronization is one of the key components of the TSN toolset, needed for equipment used in packet networks where time-sensitive functions are performed. IEEE 802.1AS is used in several applications, such as Audio and Video, Industrial Automation (e.g. smart manufacturing), Automotive, and Aerospace.
Driving Digital Transformation through IEEE 802.1 TSN - An Overview of Time-Sensitive Networking
This webinar will give an introduction to the basics of IEEE 802.1 Time-Sensitive Networking (TSN), including base concepts and application areas. TSN provides deterministic data packet transport such that packets are delivered within a time window without loss or delay due to congestion or errors. The various TSN techniques are specified by a set of base IEEE 802® TSN standards, colloquially referred to as the “TSN toolset”. In order to facilitate the adoption of TSN, industry-specific “TSN profile” standards to select which of the base standards in the TSN toolset to use, and how to use them in a given industry vertical.
The Impact of Time-Sensitive Networks - An Introduction to IEEE 802.1
This webinar will give an introduction to the market-relevant standards of the IEEE 802.1 Working Group. This group was created over 40 years ago and developed the base architecture and bridging standards for IEEE 802 technologies. While MAC bridging has evolved into VLAN bridging it has also been enhanced with features supporting time-sensitive networking (TSN). In addition, the WG has also developed other higher-layer standards including link aggregation (LAG), link discovery (LLDP), encryption (MACsec), and authentication (1X). Recently the group has developed profiles of TSN features for specific verticals.
